Syringe Pump

Syringe Pump

R11,600.00 Inc Vat

Medical Programmable Automatic Syringe Pump with Ce Approved

Note: Portable Electronic injection single channel ambulance syringe pump is compatible with syringe of any standard.
Features(optional):
1) Simple structure in linear type ,easy in installation and maintain.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatisation and intellectualisation pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Features And Advantages:

  • High accuracy ±2%, high consistency.
  • Multiple work modes and multiple drug units
  • Anti-Bolus can release pressure automatically when occlusion alarms happens
  • Several occlusion pressure alarm can meet different pressure requirement for drugs, and improve the safety in the clinic use.
  • Key lock avoids mis operation and improve safety.

Specification

ModelKL-602

Syringe Size

10, 20, 30, 50/60 ml

Applicable SyringeCompatible with syringe of any standard

VTBI

0.1-9999 ml
＜1000 ml in 0.1 ml increments
≥1000 ml in 1 ml increments
Flow RateSyringe 10 ml: 0.1-400 ml/h
Syringe 20 ml: 0.1-600 ml/h
Syringe 30 ml: 0.1-900 ml/h
Syringe 50/60 ml: 0.1-1300 ml/h
＜100 ml/h in 0.1 ml/h increments
≥100 ml/h in 1 ml/h increments

Bolus Rate

Syringe 10 ml: 400 ml/h
Syringe 20 ml: 600 ml/h
Syringe 30 ml: 900 ml/h
Syringe 50/60 ml: 1300 ml/h
Anti-BolusAutomatic
Accuracy±2% (mechanical accuracy ≤1%)
Infusion ModeMemory mode
Flow rate: ml/min, ml/h
Time-based
Body weight: mg/kg/min, mg/kg/h, ug/kg/min, ug/kg/h etc.
KVO Rate

0.1-1 ml/h (in 0.1 ml/h increments)

Alarms

Occlusion, near empty, end program, low battery, end battery,
AC power off, motor malfunction, system malfunction, reminder alarm, pressure sensor error, syringe installation error, syringe drop off
Additional FeaturesReal-time infused volume, automatic power switching,
automatic syringe identification, mute key, purge, bolus, anti-bolus,
system memory
Drug Library

Available

Occlusion Sensitivity

High, medium, low

Power Supply, AC

110/230 V (optional), 50/60 Hz, 20 VA
Battery9.6±1.6 V, rechargeable
Battery Life7 hours at 5 ml/h

Working Temperature

5-40℃

Relative Humidity

20-90%
Atmospheric Pressure860-1060 hpa

Size

314*167*140 mm
Weight2.5 kg

Safety Classification

Class Ⅱ, type CF

3 in stock

SKU: kl-602 Categories: ,
Weight5 kg
Dimensions40 × 30 × 30 cm
